Graphics Engine
|
AMD Radeon RX 9070
|
|
Stream Processor
|
3584 Units
|
|
Video Memory
|
16GB GDDR6
|
|
Memory Interface
|
256-bit
|
|
Engine Clock(OC)
|
up to 2070MHz(Game), up to 2520MHz(Boost)
|
|
Bus Standard
|
PCIE 5.0 x16
|
|
Standard Display Connectors
|
1x HDMI 2.1b, 3x DisplayPort 2.1a (only 2x simultaneous DP2.1 connections can be supported)
|
|
DirectX® Support
|
12
|
|
OpenGL
|
4.6
|
|
Maximum Resolution
|
7680 × 4320
|
|
Board Dimensions
|
289 x 111 x 41 mm, 304 x 127 x 42 mm(with bracket)
|
|
Slots
|
2
|
|
Minimum System Power requirement
|
650 W
|
|
Extension Power Connector
|
Two 8-pin PCI Express Power connectors
|
