APC Basic Rack-Mount PDU Strømfordelingsenhed 24-stik 16A Sort 3.05m
APC Basic Rack-Mount PDU - Strømfordelingsenhed (rackversion) - AC 230 V - 3680 Watt - input: IEC 60320 C20 - output-stikforbindelser: 24 (power IEC 60320 C13, IEC 60320 C19) - 3.05 m ledning - sort - for P/N: SMX1000C, SMX1500RM2UC, SMX1500RM2UCNC, SMX750C, SMX750CNC, SRT5KRMXLW-TW
5 117,00SEK4 093,60SEK excl. VAT
-
Product no 489278
Model AP7552
Brand APC
EAN 0731304207900
Weight 7.25 kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | APC Basic Rack-Mount PDU - strømfordelingsenhed - 3680 Watt |
| Enhedstype | Strømfordelingsenhed - rackversion |
| Ledningslængde | 3.05 m |
| Vægt | 4.9 kg |
| Indgangspænding | AC 230 V |
| Udgangspænding | AC 230 V |
| Strømkapacitet | 3680 Watt |
| Input-stik | 1 x strøm IEC 60320 C20 |
| Output-stikforbindelser | 20 x power IEC 60320 C13<br>4 x strøm IEC 60320 C19 |
| Farve | Sort |
| Dimensioner (B x D x H) | 5.6 cm x 4.4 cm x 161.9 cm |
| Producentgaranti | 2 års garanti |
| Designet for | P/N: AR3357X674, SMT2200I-AR, SMT2200R2I-AR, SMT3000I-AR, SMT3000R2I-AR, SMX1000C, SMX1500RM2UC, SMX1500RM2UCNC, SMX1500RMNCUS, SMX1500RMUS, SMX3000RMLVUS, SMX3KRMLVNCUS, SMX750C, SMX750CNC, SRT1000RMXLI, SRT1000RMXLI-NC, SRT10RMXLIX806, SRT1500XLI, SRT2200XLI-KR, SRT5KRMXLTUS, SRT5KRMXLW-TW |
| General | |
|---|---|
| Color | Black |
| Cord Length | 3.05 m |
| Device Type | Power distribution strip - rack-mountable |
| Power Device | |
| Frequency Provided | 50/60 Hz |
| Frequency Required | 50/60 Hz |
| Input Connectors | 1 x power IEC 60320 C20 |
| Input Voltage | AC 230 V |
| Max Electric Current | 16 A |
| Output Voltage | AC 230 V 50/60 Hz |
| Power Capacity | 3680 Watt |
| Power Output Connectors Details | 20 x power IEC 60320 C13 | 4 x power IEC 60320 C19 |
| Miscellaneous | |
| Cables Included | Power cable - external - 3.05 m |
| Compliant Standards | EN 60950, VDE |
| Rack Mounting Kit | Included |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 2 years | Limited warranty - replacement - 2 years |
| Environmental Parameters | |
| Humidity Range Operating | 5 - 95% |
| Humidity Range Storage | 5 - 95% |
| Max Operating Temperature | 45 °C |
| Max Storage Temperature | 65 °C |
| Min Operating Temperature | 0 °C |
| Min Storage Temperature | -25 °C |
| Dimensions & Weight | |
| Depth | 4.4 cm |
| Height | 161.9 cm |
| Weight | 4.9 kg |
| Width | 5.6 cm |
| Compatibility Information | |
| Designed For | P/N: AR2487G, AR3100W, AR3105SP, AR3105W, AR3140G, AR3140W, AR3150W, AR3155SP, AR3155W, AR3157SP, AR3300SP, AR3300W, AR3305SP, AR3305W, AR3307SP, AR3340G, AR3340W, AR3350SP, AR3350W, AR3355SP, AR3355W, AR3357SP, AR3357X674, NBPD0160A, NBWL0355A, NBWL |
