Denne APC fra Schneider Electric Smart-UPS X er en højtydende Uninterruptible Power Supply (UPS). Den beskytter elektronisk udstyr mod strømafbrydelser, delvise strømudfald og udsving i strømstyrken, små udsving i strømstyrken samt større forstyrrelser. UPS'en leverer også batteribackup, indtil strømmen fra netstrømforsyningen vender tilbage til et sikkert niveau, eller til batterierne er helt afladet.
Product no 988255828
Model SMX2200RMHV2U
Brand APC
EAN 0731304272687
Weight 46 kg
Produktbeskrivelse | APC Smart-UPS X 2200 Rack/Tower LCD - UPS - 1980 Watt - 2200 VA |
Enhedstype | UPS - stativ-monterbar / ekstern |
Rackstørrelse | 2U |
Vægt | 37.32 kg |
Indgangspænding | AC 208/220/230/240 V |
Udgangspænding | AC 208/220/230/240 V ± 5% |
Strømkapacitet | 1980 Watt / 2200 VA |
Input-stik | 1 x strøm IEC 60320 C20, strøm BS 1363A, Europlug (strøm CEE 7/16) |
Output-stikforbindelser | 8 x power IEC 60320 C13<br>1 x strøm IEC 60320 C19 |
Batteri | Blysyre |
Antal batterier | 1 |
Driftstid (op til) | 9.8 min ved fuld belastning |
Netværk | RS-232, USB |
Farve | Sort |
Dimensioner (B x D x H) | 43.2 cm x 66.7 cm x 8.5 cm |
Producentgaranti | 3 års garanti |
Designet for | P/N: AR2487G, AR3100W, AR3105SP, AR3105W, AR3140G, AR3140W, AR3155W, AR3305W, AR3340G, AR3355SP, AR3355W, AR4018IX429, AR4018SP, AR4018SPX429, AR4018SPX431, AR4018SPX432, AR4018X429, AR4024IX431, AR4024SP, AR4024SPX429, AR4024SPX431, AR4024SPX432, AR4038IX432, NBWL0356A, SMX2000LVNCUS, SRT1500RMXLA |
General | |
---|---|
Color | Black |
Device Type | UPS - rack-mountable / external |
Height (Rack Units) | 2U |
Power Device | |
Circuit Protection | Circuit breaker |
Frequency Provided | 50/60 Hz |
Frequency Required | 50/60 Hz |
Input Connectors | 1 x power IEC 60320 C20, power BS 1363A, Europlug (power CEE 7/16) |
Input Voltage | AC 208/220/230/240 V |
Input Voltage Range | AC 140 - 280 V |
Output Voltage | AC 208/220/230/240 V ± 5% - 50/60 Hz |
Output Waveform | Sinewave |
Power Capacity | 1980 Watt / 2200 VA |
Power Output Connectors Details | 8 x power IEC 60320 C13 | 1 x power IEC 60320 C19 |
Surge Energy Rating | 645 Joules |
Surge Suppression | Yes |
UPS Technology | Line interactive |
Battery | |
Quantity | 1 |
Recharge Time | 3 hours |
Run Time (Up To) | 9.8 min at full load | 25.3 min at half load |
Technology | Lead acid |
Transfer Time | 4 ms |
Networking | |
Remote Management Interface | RS-232, USB |
Expansion / Connectivity | |
Expansion Slots | 1 (total) / 1 (free) x SmartSlot |
Interfaces | 1 x management (USB) - 4 pin USB Type B | 1 x EPO (emergency power off) | 1 x management (RS-232) - RJ-45 |
Miscellaneous | |
Cables Included | Serial cable | USB cable | Power cable 1.83 m |
Compliant Standards | CSA, C-Tick, GOST, UL 1449, UL 1778, VDE, IEC 60950, EN 50091-2, IRAM, RoHS, EN 50091-1, FCC Part 15 A, REACH |
Features | Audible alarm, emergency power off, Automatic Voltage Regulation (AVR), LED indicators, automatic self-test, hot-swappable batteries |
Rack Mounting Kit | Included |
Software / System Requirements | |
Software Included | APC PowerChute Business Edition |
Manufacturer Warranty | |
Service & Support | Limited warranty - 3 years | Limited warranty - batteries - 2 years |
Environmental Parameters | |
Humidity Range Operating | 0 - 95% |
Max Operating Temperature | 40 °C |
Min Operating Temperature | 0 °C |
Sound Emission | 55 dBA |
Dimensions & Weight | |
Depth | 66.7 cm |
Height | 8.5 cm |
Weight | 37.32 kg |
Width | 43.2 cm |
Dimensions & Weight (Shipping) | |
Shipping Depth | 86.9 cm |
Shipping Height | 24.3 cm |
Shipping Weight | 45.36 kg |
Shipping Width | 59.6 cm |
Compatibility Information | |
Designed For | P/N: ACDC2513, AR2200, AR2280, AR2400, AR2400FP1, AR2401, AR2407, AR2480, AR2487, AR2487G, AR2500, AR2507, AR2580, AR2587, AR3100G, AR3100TAA, AR3100W, AR3100X609, AR3100X610, AR3100X617, AR3105SP, AR3105W, AR3107G, AR3107SP, AR3107X609, AR3140G, AR3 |
