Produktbeskrivelse
|
Argus APS-720W - strømforsyning - 720 watt
|
|
Enhedstype
|
Strømforsyning - aktiv Power Factor Correction (PFC) - intern
|
|
Specifikationsoverensstemmelse
|
ATX12V 2.31
|
|
Vægt
|
1.41 kg
|
|
Indgangspænding
|
AC 115/230 V
|
|
Udgangspænding
|
+3.3, +5, ±12 V
|
|
Strømkapacitet
|
720 watt
|
|
Output Current
|
+12V1 - 30 A<br>+12V2 - 30 A<br>+3.3V - 18 A<br>+5V - 15 A<br>-12V - 0.3 A<br>+5VSB - 3 A
|
|
Output-stikforbindelser
|
1 x strøm 24 pin ATX med aftagelig 4 pin sektion<br>1 x strøm 8 pin +12 V med aftagelig 4 pin sektion<br>2 x 8 pin PCI Express-strøm med aftagelig 2 pin sektion<br>4 x 15 pin Serial ATA strøm<br>4 x 4-PIN intern strøm<br>1 x 4-PIN mini-strømforsyningsforbinder
|
|
Kølesystem
|
120 mm ventilator
|
|
Udstyr inkluderet
|
Kabelbånd
|
|
Dimensioner (B x D x H)
|
15 cm x 14 cm x 8.6 cm
|
|
Producentgaranti
|
2 års garanti
|
Denmark's wildest electronics webshop is now available in Sweden
Argus APS-720W 720Watt
Argus APS-720W - Strømforsyning (intern) - ATX12V 2.31 - AC 115/230 V - 720 watt - aktiv PFC
SEK 355,00
SEK 284,00 excl. VAT
SEK 355,00
SEK 284,00 excl. VAT
Shipping from SEK 39,00 (PostNord Spårbart varubrev)
Product no:
988795009
Model:
88882119
EAN:
4260133126039
Brand:
Weight:
1.57 kg
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
Specifications
Full specifications
|
General
|
|
|---|---|
|
Device Type
|
Power supply - active Power Factor Correction (PFC) - internal
|
|
PSU Form Factor
|
ATX
|
|
Specification Compliance
|
ATX12V 2.31
|
|
Power Device
|
|
|
Efficiency
|
82%
|
|
Frequency Required
|
47 - 63 Hz
|
|
Input Voltage
|
AC 115/230 V
|
|
Output Current
|
+12V1 - 30 A | +12V2 - 30 A | +3.3V - 18 A | +5V - 15 A | -12V - 0.3 A | +5VSB - 3 A
|
|
Output Voltage
|
+3.3, +5, ±12 V
|
|
Power Capacity
|
720 Watt
|
|
Power Output Connectors Details
|
1 x power 24 pin ATX with detachable 4 pin section | 1 x power 8 pin +12V with detachable 4 pin section | 2 x 8 pin PCI Express power with detachable 2 pin section | 4 x 15 pin Serial ATA power | 4 x 4 pin internal power | 1 x 4 pin mini-power connec
|
|
Miscellaneous
|
|
|
Compliant Standards
|
FCC, RoHS, WEEE
|
|
Cooling System
|
120 mm fan
|
|
Features
|
Overcurrent protection, short-circuit protection, thermal protection
|
|
Included Accessories
|
Cable ties
|
|
Manufacturer Warranty
|
|
|
Service & Support
|
Limited warranty - 2 years
|
|
Dimensions & Weight
|
|
|
Depth
|
14 cm
|
|
Height
|
8.6 cm
|
|
Weight
|
1.41 kg
|
|
Width
|
15 cm
|
|
Dimensions & Weight (Shipping)
|
|
|
Shipping Depth
|
9.5 cm
|
|
Shipping Height
|
17 cm
|
|
Shipping Weight
|
1.75 kg
|
|
Shipping Width
|
24 cm
|
