Produktbeskrivelse
|
Argus GPS-800 - strømforsyning - 800 watt
|
|
Enhedstype
|
Strømforsyning - intern
|
|
Specifikationsoverensstemmelse
|
ATX12V 2.4
|
|
80 PLUS certificering
|
80 PLUS Gold
|
|
Vægt
|
1.98 kg
|
|
Indgangspænding
|
AC 100/240 V
|
|
Udgangspænding
|
+3.3, +5, ±12 V
|
|
Strømkapacitet
|
800 watt
|
|
Output Current
|
+12V - 66 A<br>+3.3V - 20 A<br>+5V - 20 A<br>-12V - 0.3 A<br>+5VSB - 2.5 A
|
|
Output-stikforbindelser
|
1 x strøm 24 pin ATX med aftagelig 4 pin sektion<br>2 x strøm 8 pin +12 V med aftagelig 4 pin sektion<br>4 x 8 pin PCI Express-strøm med aftagelig 2 pin sektion<br>6 x 15 pin Serial ATA strøm<br>3 x 4-PIN intern strøm<br>1 x 4-PIN mini-strømforsyningsforbinder
|
|
Kølesystem
|
140 mm ventilator
|
|
Dimensioner (B x D x H)
|
15 cm x 16 cm x 8.6 cm
|
|
Producentgaranti
|
5 års garanti
|
Denmark's wildest electronics webshop is now available in Sweden
Argus GPS-800 800Watt 80 PLUS Gold
Argus GPS-800 - Strømforsyning (intern) - ATX12V 2.4 - 80 PLUS Gold - AC 100/240 V - 800 watt
Specifications
Full specifications
|
General
|
|
|---|---|
|
Device Type
|
Power supply - internal
|
|
PSU Form Factor
|
ATX
|
|
Specification Compliance
|
ATX12V 2.4
|
|
Power Device
|
|
|
80 PLUS Certification
|
80 PLUS Gold
|
|
Efficiency
|
93.4%
|
|
Frequency Required
|
47 - 63 Hz
|
|
Input Voltage
|
AC 100/240 V
|
|
Output Current
|
+12V - 66 A | +3.3V - 20 A | +5V - 20 A | -12V - 0.3 A | +5VSB - 2.5 A
|
|
Output Voltage
|
+3.3, +5, ±12 V
|
|
Power Capacity
|
800 Watt
|
|
Power Output Connectors Details
|
1 x power 24 pin ATX with detachable 4 pin section | 2 x power 8 pin +12V with detachable 4 pin section | 4 x 8 pin PCI Express power with detachable 2 pin section | 6 x 15 pin Serial ATA power | 3 x 4 pin internal power | 1 x 4 pin mini-power connec
|
|
Miscellaneous
|
|
|
Cooling System
|
140 mm fan
|
|
Features
|
Overcurrent protection, overvoltage protection, overpower protection, short-circuit protection, Intelligent Fan Control Technology, no load operation protection
|
|
Manufacturer Warranty
|
|
|
Service & Support
|
Limited warranty - 5 years
|
|
Dimensions & Weight
|
|
|
Depth
|
16 cm
|
|
Height
|
8.6 cm
|
|
Weight
|
1.98 kg
|
|
Width
|
15 cm
|
|
Dimensions & Weight (Shipping)
|
|
|
Shipping Weight
|
2.33 kg
|
