Product no 998088641
Model 01995-001
Brand Axis Communications
EAN 7331021070561
Weight 1.04 kg
Produktbeskrivelse | Axis I8016-LVE - IP-intercomstation - NCS S 9000-N |
Produkttype | IP-intercomstation vægmontering |
Miljø | Udendørs |
Placering/montering | Vægmontering |
Funktioner | Bevægelsesdetektion, kamera |
Integrerede sensorer | Temperatur |
Integrerede komponenter | Mikrofon, højttaler, kamera |
Strømkilde | PoE |
Forbindelse | Kabling - 10/100 Ethernet |
Inputtype | 1 knapper |
Kamera | RGB CMOS 1/2.7" - Maksimum opløsning 2592 x 1944 Dag/nat |
Farve | NCS S 9000-N |
Producentgaranti | 5 års garanti |
Dimensioner (B x D x H) | 12.4 cm 12.4 cm |
General | |
---|---|
Connectivity Technology | Wired - Ethernet, Fast Ethernet |
Environment | Outdoor |
Features | E-mail notification, H.264 streaming video, SIP compliant, MJPEG streaming video, MPEG-4 streaming video, audio detection, casing open detection, H.265 streaming video, PoE, power over Ethernet (PoE), ARP support, auto-uplink (auto MDI/MDI-X), Syslog |
Functions | Motion detection, camera |
Integrated Components | Microphone, speaker, camera |
Integrated Sensors | Temperature |
Interfaces | 6-pin terminal block | Relay | LAN/power | 4-pin terminal block |
Placing / Mounting | Wall-mounting |
Power Source | PoE |
Product Type | IP intercom station wall mount |
Control Unit | |
Built-in Devices | Microphone, speaker, camera, microSD card reader, microSDHC card reader |
Buttons Qty | 1 |
Camera | |
Day & Night Functionality | Yes |
Features | Sharpness control, white balance, saturation control, brightness control, contrast control, Camera Tampering Detection, microSDXC card slot, shock detection, tone correction, Zipstream technology, ONVIF (Profile S) support, ONVIF (Profile G) support, |
Focal Length | 1.95 mm |
Image Sensor | RGB CMOS - 1/2.7" |
Lens Aperture | F/2.2 |
Max Digital Video Resolution | 2592 x 1944 |
RAM | |
Installed Size | 2048 MB |
Flash Memory | |
Installed Size | 512 MB |
Supported Flash Memory Cards | microSDHC, microSD |
Software | |
Type | AXIS Camera Station, AXIS Companion |
Miscellaneous | |
Color | NCS S 9000-N |
Compliant Standards | EN 61000-6-1, EN 61000-6-2, FIPS 140-2, IEC 60068-2-27, IEC 60068-2-6, IK10, FCC Part 15 B Class A, IP66, EN 50121-4, IEC 62236-4, VCCI Class A, IEC 62471, NEMA250 Type 4X, AS/NZS CISPR 32 Class A, EN 55032 Class A, KCC KN32 Class A, IEC/EN/UL 60950- |
Power Provided | 4.7 Watt |
Product Material | Plastic, stainless steel |
Rated Current | 0.7 A |
Warranty | 5-year warranty |
Dimensions & Weight | |
Height | 12.4 cm |
Weight | 900 g |
Width | 12.4 cm |
Environmental Parameters | |
Humidity Range Operating | 10 - 85% (non-condensing) |
Max Operating Temperature | 60 °C |
Min Operating Temperature | -40 °C |
