Product no 998410325
Model E659395
Brand Elo TouchSystems
EAN 0843173135472
Weight 12.49 kg
Produktbeskrivelse | Elo 2403LM - Medical Grade - LCD-skærm - Full HD (1080p) - 24" |
Enhedstype | LCD-skærm - 24" - touchscreen |
Egenskaber | Touch-screen, USB-hub |
Formatforhold | 16:9 |
Standard opløsning | Full HD (1080p) 1920 x 1080 ved 60 Hz |
Lysstyrke | 250 cd/m² |
Kontrastforhold | 1000:1 |
Responstid | 15 ms (tr - tf) |
Farve support | 16,7 millioner farver |
Input-stik | HDMI, VGA |
Spænding | AC 120/230 V (50/60 Hz) |
Farve | Hvid |
Dimensioner (B x D x H) - med stander | 57.46 cm x 23.3 cm x 43.29 cm |
Vægt | 8.7 kg |
Overensstemmelsesstandarder | UL, VCCI, BSMI, cUL, CB, CCC, IC, FCC, KCC, DICOM Part 14, IP54, IEC 60601-1, ISO 14971, EAC, RCM, ANSI/AAMI ES60601-1, CoC, CAN/CSA C22.2 No. 60601-1:14, IEC 60601-1:2005 + A1:2012 |
Producentgaranti | 3 års garanti |
General | |
---|---|
Aspect Ratio | 16:9 |
Brightness | 250 cd/m² |
Brightness w/touchscreen | 240 cd/m² |
Built-in Devices | USB hub |
Color | White |
Color Support | 16.7 million colors |
Contrast Ratio | 1000:1 |
Diagonal Size | 24" |
Dimensions (WxDxH) | 57.46 cm x 23.3 cm x 43.29 cm - with stand |
Display Type | LCD monitor / TFT active matrix |
Features | TouchPro technology, DICOM Compliant |
Horizontal Refresh Rate | 30 - 82 kHz |
Horizontal Viewing Angle | +89 / -89 |
Native Resolution | Full HD (1080p) 1920 x 1080 at 60 Hz |
OSD Languages | Chinese (traditional), Chinese (simplified), English, German, French, Italian, Russian, Spanish, Japanese, Korean |
Response Time | 15 ms (tr - tf) |
Vertical Refresh Rate | 50 - 75 Hz |
Vertical Viewing Angle | +89 / -89 |
Viewable Size | 23.8" |
Weight | 8.7 kg |
Audio | |
Output Power / Channel | 2 Watt |
Type | Speakers - stereo |
Input | |
Movement Detection Technology | Projected capacitive |
Type | Touchscreen - touchscreen |
Connectivity | |
Interfaces | HDMI | VGA | Audio line-out (mini-jack) | USB (Type B) | USB 2.0 (Type A) | 4 x Micro-USB |
Mechanical | |
VESA Mounting Interface | 100 x 100 mm |
Miscellaneous | |
Cables Included | 1 x VGA cable | 1 x HDMI cable | 1 x USB cable | 1 x audio cable |
Compliant Standards | UL, VCCI, BSMI, cUL, CB, CCC, IC, FCC, KCC, DICOM Part 14, IP54, IEC 60601-1, ISO 14971, EAC, RCM, ANSI/AAMI ES60601-1, CoC, CAN/CSA C22.2 No. 60601-1:14, IEC 60601-1:2005 + A1:2012 |
MTBF | 50,000 hours |
Power | |
Input Voltage | AC 120/230 V (50/60 Hz) |
Power Consumption (Typical) | 25.5 Watt |
Power Consumption Sleep | 0.33 Watt |
Dimensions & Weight (Shipping) | |
Shipping Depth | 31.8 cm |
Shipping Height | 52.6 cm |
Shipping Weight | 12 kg |
Shipping Width | 68 cm |
Manufacturer Warranty | |
Service & Support | Limited warranty - 3 years |
Environmental Parameters | |
Humidity Range Operating | 20 - 80% (non-condensing) |
Max Operating Temperature | 40 °C |
Min Operating Temperature | 0 °C |
