Elo Open-Frame Touchmonitors 1790L 17" 1280 x 1024 VGA (HD-15) HDMI DisplayPort 60Hz
Elo Open-Frame Touchmonitors 1790L - Rev B - LED-skærm - 17" - åben ramme - berøringsskærm - 1280 x 1024 @ 60 Hz - 250 cd/m² - 1000:1 - 5 ms - HDMI, VGA, DisplayPort - sort
7 443,00 SEK
5 954,40 SEK excl. VAT
-
Product no 992629404
Model E326942
Brand Elo TouchSystems
EAN 0815335025822
Weight 5.18 kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | Elo Open-Frame Touchmonitors 1790L - Rev B - LED-skærm - 17" |
| Enhedstype | LED-baggrundsbelyst LCD-skærm - 17" - berøringsskærm |
| Energiklasse | Klasse B |
| Energiforbrug om året | 30 kWt |
| Strømforbrug (Til-modus) | 20 W |
| Egenskaber | Touch-screen, fjernstyring |
| Formatforhold | 5:4 |
| Standard opløsning | 1280 x 1024 ved 60 Hz |
| Lysstyrke | 250 cd/m² |
| Kontrastforhold | 1000:1 |
| Responstid | 5 ms |
| Farve support | 16,7 millioner farver |
| Input-stik | HDMI, VGA, DisplayPort |
| Skærmbelægning | Blændfri |
| Spænding | AC 120/230 V (50/60 Hz) |
| Farve | Sort |
| Dimensioner (B x D x H) | 36.84 cm x 4.75 cm x 30.64 cm |
| Vægt | 3.6 kg |
| Overensstemmelsesstandarder | UL, TUV, VCCI, BSMI, cUL, CB, CCC, IC, FCC, RoHS, KCC, WEEE, China RoHS, RCM, CoC, DisplayPort 1.1a, IMERC |
| Producentgaranti | 3 års garanti |
| General | |
|---|---|
| Aspect Ratio | 5:4 |
| Backlight Technology | LED backlight |
| Brightness | 250 cd/m² |
| Brightness w/touchscreen | 225 cd/m² |
| Color | Black |
| Color Support | 16.7 million colors |
| Contrast Ratio | 1000:1 |
| Diagonal Size | 17" |
| Dimensions (WxDxH) | 36.84 cm x 4.75 cm x 30.64 cm |
| Display Type | LED-backlit LCD monitor / TFT active matrix |
| Energy Class | Class B |
| Energy Consumption per Year | 30 kWh |
| Features | Remote OSD, IntelliTouch Surface Acoustic Wave |
| Horizontal Refresh Rate | 30 - 82 kHz |
| Horizontal Viewing Angle | +85 / -85 |
| Native Resolution | 1280 x 1024 at 60 Hz |
| OSD Languages | Chinese (traditional), Chinese (simplified), English, German, French, Italian, Spanish, Japanese |
| Response Time | 5 ms |
| Screen Coating | Anti-glare |
| Vertical Refresh Rate | 50 - 75 Hz |
| Vertical Viewing Angle | +80 / -80 |
| Weight | 3.6 kg |
| Input | |
| Movement Detection Technology | Intellitouch SAW |
| Type | Touchscreen, remote control - touchscreen |
| Connectivity | |
| Interfaces | USB | VGA | DisplayPort | HDMI | Serial |
| Mechanical | |
| VESA Mounting Interface | 100 x 100 mm, 75 x 75 mm |
| Miscellaneous | |
| Cables Included | 1 x USB cable | 1 x VGA cable | 1 x HDMI cable |
| Compliant Standards | UL, TUV, VCCI, BSMI, cUL, CB, CCC, IC, FCC, RoHS, KCC, WEEE, China RoHS, RCM, CoC, DisplayPort 1.1a, IMERC |
| Mounting Kit | Included |
| MTBF | 50,000 hours |
| Power | |
| Input Voltage | AC 120/230 V (50/60 Hz) |
| Power Consumption (On mode) | 20 W |
| Power Consumption (Typical) | 17.8 Watt |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Environmental Parameters | |
| Humidity Range Operating | 20 - 80% (non-condensing) |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
