Product no 999613861
Model PPA9000600
Brand FSP Group
EAN 4713224523823
Weight 4.61 kg
Produktbeskrivelse | FSP Twins Pro FSP900-50REB - strømforsyning - 900 Watt |
Enhedstype | Strømforsyning - aktiv Power Factor Correction (PFC) - intern |
Specifikationsoverensstemmelse | ATX12V |
80 PLUS certificering | 80 PLUS Gold |
Indgangspænding | AC 100-240 V |
Udgangspænding | DC +3.3, DC +5, DC ±12 V |
Strømkapacitet | 900 Watt |
Overskudsspænding | Ja |
Output Current | +3.3V - 20 A<br>+5V - 20 A<br>+12V - 71 A<br>-12V - 0.5 A<br>+5VSB - 3 A |
Output-stikforbindelser | 1 x strøm 24 pin ATX med aftagelig 4 pin sektion<br>2 x strøm 8 pin +12 V med aftagelig 4 pin sektion<br>4 x 8 pin PCI Express-strøm med aftagelig 2 pin sektion<br>6 x 15 pin Serial ATA strøm<br>2 x 4-PIN intern strøm<br>1 x 4-PIN mini-strømforsyningsforbinder |
Kølesystem | 40mm blæser |
Dimensioner (B x D x H) | 15 cm x 19 cm x 8.6 cm |
Producentgaranti | 5 års garanti |
General | |
---|---|
Device Type | Power supply - active Power Factor Correction (PFC) - internal |
PSU Form Factor | ATX |
Specification Compliance | ATX12V |
Power Device | |
80 PLUS Certification | 80 PLUS Gold |
Efficiency | 90% |
Frequency Required | 50 - 60 Hz |
Input Voltage | AC 100-240 V |
Installed Power Modules | 2 |
Output Current | +3.3V - 20 A | +5V - 20 A | +12V - 71 A | -12V - 0.5 A | +5VSB - 3 A |
Output Voltage | DC +3.3, DC +5, DC ±12 V |
Power Capacity | 900 Watt |
Power Output Connectors Details | 1 x power 24 pin ATX with detachable 4 pin section | 2 x power 8 pin +12V with detachable 4 pin section | 4 x 8 pin PCI Express power with detachable 2 pin section | 6 x 15 pin Serial ATA power | 2 x 4 pin internal power | 1 x 4 pin mini-power connec |
Power Redundancy | Yes |
Power Redundancy Scheme | 1+1 |
Supported Power Modules | 2 |
Miscellaneous | |
Cooling System | 40 mm fan |
Features | Overheat protection, overcurrent protection, overvoltage protection, overpower protection, undervoltage protection, hot swappable PSU, short-circuit protection, triple 12V rails, dual ball bearing cooling fan, non-modular, fan failure protection, cab |
Manufacturer Warranty | |
Service & Support | Limited warranty - 5 years |
Dimensions & Weight | |
Depth | 19 cm |
Height | 8.6 cm |
Width | 15 cm |
