TRENDnet TI-F11SFP Medieomsætter
TRENDnet TI-F11SFP - Medieomsætter - 1GbE - 10Base-T, 100Base-TX, 1000Base-T - RJ-45 / SFP (mini-GBIC) - TAA-kompatibel
-
Product no 989882590
Model TI-F11SFP
Brand
Go to brand's websiteEAN 0710931160369
Weight 0.43 kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | TRENDnet TI-F11SFP - medieomsætter - 10Mb LAN, 100Mb LAN, 1GbE - TAA-kompatibel |
| Enhedstype | Medieomsætter - RJ-45 / SFP (mini-GBIC) |
| Model | Monterbar på DIN rail |
| Kabeltype | 10Base-T, 100Base-TX, 1000Base-T |
| Dataoverførselshastighed | 2 Gbps |
| Dataforbindelsesprotokol | 10Mb LAN, 100Mb LAN, 1GbE |
| Effekt | DC 12 - 56 V - strømadapter ikke inkluderet |
| Dimensioner (B x D x H) | 11.3 cm x 3.1 cm x 8.2 cm |
| Vægt | 152 g |
| TAA kompatibel | Ja |
| Producentgaranti | 3 års garanti |
| General | |
|---|---|
| Device Type | Media converter |
| Form Factor | DIN rail mountable |
| Networking | |
| Cabling Type | 10Base-T, 100Base-TX, 1000Base-T |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3x |
| Connectivity Technology | Wired |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, GigE |
| Data Transfer Rate | 2 Gbps |
| Features | Auto-negotiation, store and forward, half duplex mode, full duplex mode, Link Fault Pass Through function (LFP), wall mountable, Jumbo Frames support, built-in DIP switch, 8KV ESD Protector, 6KV Surge protection |
| Expansion / Connectivity | |
| Interfaces | 1 x Ethernet 1000Base-T - RJ-45 female | 1 x - SFP |
| Miscellaneous | |
| Compliant Standards | EN55022, EN55024, RoHS, WEEE, IEC 60068-2-27, IEC 60068-2-32, IEC 60068-2-6, EN 55011, FCC Part 15 B Class A, IP30 |
| Included Accessories | DIN-rail mounting kit, wall mounting kit, removable terminal block |
| MTBF | 510,304 hours |
| Power | |
| Max Supported Qty | 2 |
| Power Consumption Operational | 3 Watt |
| Power Device | External power adapter (not included) |
| Power Redundancy | Yes |
| Voltage Required | DC 12 - 56 V |
| Dimensions & Weight | |
| Depth | 3.1 cm |
| Height | 8.2 cm |
| Weight | 152 g |
| Width | 11.3 cm |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Environmental Parameters | |
| Humidity Range Operating | 0 - 95% (non-condensing) |
| Max Operating Temperature | 75 °C |
| Min Operating Temperature | -40 °C |
