Specifications

HPE 562T - Netværksadapter - PCIe 3.0 x4 - 10Gb Ethernet x 2 - for Apollo 4200 Gen10; Nimble Storage dHCI Large Solution with HPE ProLiant DL380 Gen10

3 718,00SEK2 974,40SEK excl. VAT

Product no 992837398

Model 817738-B21

Brand Hewlett Packard Ente

EAN 4514953893580

Weight 0.32 kg
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.

Produktbeskrivelse	HPE 562T - netværksadapter - PCIe 3.0 x4 - 10Gb Ethernet x 2
Enhedstype	Netværksadapter
Model	Indstikskort
Grænseflade (bus) type	PCI Express 3.0 x4
Porte	10Gb Ethernet x 2
Dataforbindelsesprotokol	10GbE
Dataoverførselshastighed	10 Gbps
Processor	1 x Intel X550-AT2
Overensstemmelsesstandarder	IEEE 802.1Q, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1as, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qau, IEEE 802.1Qbg
Producentgaranti	1 års garanti
Designet for	Apollo 4200 Gen10; Nimble Storage dHCI Large Solution with HPE ProLiant DL380 Gen10; ProLiant DL180 Gen10, DL20 Gen10, DL325 Gen10, DL360 Gen10, DL380 Gen10, DL388 Gen10, DX380 Gen10, DX560 Gen10, ML110 Gen10, ML30 Gen10, ML350 Gen10, XL170r Gen10, XL190r Gen10, XL270d Gen10; StoreEasy 1660

General
Device Type	Network adapter
Form Factor	Plug-in card
Interface (Bus) Type	PCI Express 3.0 x4
Networking
Compliant Standards	IEEE 802.1Q, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1as, IEEE 802.1Qbb, IEEE 802.1Qaz, IEEE 802.1Qau, IEEE 802.1Qbg
Connectivity Technology	Wired
Data Link Protocol	10 Gigabit Ethernet
Data Transfer Rate	10 Gbps
Features	Firewall protection, IPv6 support, Jumbo Frames support, IPv4 support, PXE support, Single Root I/O Virtualization (SR-IOV), TCP Segmentation Offload (TSO), secure boot, Network Partitioning (NPAR), HPE Sea of Sensors 3D, IPv6 acceleration, firmware
Ports	10Gb Ethernet x 2
Processor / Memory
Processor	1 x Intel X550-AT2
Expansion / Connectivity
Interfaces	2 x 10Gb Ethernet - RJ-45
Miscellaneous
Compliant Standards	WHQL, WEEE, RoHS
Included Accessories	Low-profile bracket
Power
Power Consumption Operational	11.15 Watt
Manufacturer Warranty
Service & Support	Limited warranty - 1 year
Environmental Parameters
Humidity Range Operating	8 - 90% (non-condensing)
Max Operating Temperature	60 °C
Min Operating Temperature	5 °C
Compatibility Information
Designed For	HPE Apollo 4200 Gen10, 4200 Gen10 384TB 25Gb Capacity Server for Cohesity DataPlatform, 4200 Gen10 384TB Capacity Server for Cohesity DataPlatform, 4200 Gen10 for HPE Ezmeral Container Platform, 4200 Gen10 for HPE Ezmeral Tracking \| HPE Nimble Storag

HPE Ethernet 10Gb 2-port BASE-T X550-AT2 Adapter

Are you looking for a simple way to migrate to 10G high performance data center with low cost and low power in your data center? The HPE Ethernet 10Gb 2-port X550-AT2 Adapter deliver high performance and low latency for Ethernet traffic to and from the server with minimal CPU resources required. Processing of I/O packets on the adapter frees up CPU to do other more important tasks. For environments such as Telco/NFV, high-performance computing (HPC) and ecommerce that deal with large volumes of small packet traffic, these adapters accelerate small packet processing by bypassing processing in the host O/S kernel.

slide {0} of {1}, zoom in, HPE Ethernet 10Gb 2-port BASE-T X550-AT2 Adapter

Improve Application Performance

The HPE Ethernet 10Gb 2-port X550-AT2 Adapter offload packet processing to reduce CPU utilization with tunnel offloads (VXLAN and NVGRE). Now you can distribute network traffic across CPU cores in your data center.
Speeds up packet processing to service more I/O requests utilizing data plane development packet (DPDK).

Increase I/O Bandwidth for Workload Intensive Applications

The HPE Ethernet 10Gb 2-port X550-AT2 Adapter deliver single root I/O virtualization (SR-IOV) which increases virtual network performance while decreasing CPU utilization.
Provides a seamless performance upgrade from 1GBASE-T to 10GBASE-T with backward compatibility.
