Product no 996570267
Model R3V36A
Brand Hewlett Packard Ente
EAN 0190017395609
Weight 0.4 kg
Produktbeskrivelse | HPE Aruba AP-503H (RW) Unified Hospitality - trådløs forbindelse - Wi-Fi 6 |
Enhedstype | Trådløs forbindelse |
Formfaktor | Ekstern - indendørs |
Dataforbindelsesprotokol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax |
Frekvensbånd | 2.4 GHz, 5 GHz |
Præstation | Maksimum datahastighed (5 GHz): 1,2 Gbps<br>Maksimum datahastighed (2,4 GHz): 287 Mbps<br>VPN throughput (IPSec): 100 Mbps |
Kapacitet | Trådløse klienter per WiFi-radio: 256<br>BSSIDs per radio: 16 |
Power Over Ethernet (PoE) understøttet | PoE Class 3 |
Pristype | BTO |
Dimensioner (B x D x H) | 8.6 cm x 4.7 cm x 15 cm |
Vægt | 360 g |
Producentgaranti | Begrænset livtidsgaranti |
General | |
---|---|
Depth | 4.7 cm |
Device Type | Wireless access point |
Height | 15 cm |
Ruggedized Design | Indoor |
Weight | 360 g |
Width | 8.6 cm |
Networking | |
Capacity | Wireless clients per Wi-Fi radio: 256 | BSSIDs per radio: 16 |
Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, Wi-Fi CERTIFIED, IEEE 802.11n, IEEE 802.3az, IEEE 802.11ac, IEEE 802.11ax |
Connectivity Technology | Wireless |
Data Link Protocol | IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax |
Data Transfer Rate | 1.5 Gbps |
Encryption Algorithm | WPA, WPA2, WPA3-Enterprise, Opportunistic Wireless Encryption (OWE), Simultaneous Authentication of Equals (SAE) |
Features | Auto-uplink (auto MDI/MDI-X), DFS support, Wi-Fi Multimedia (WMM) support, Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, Cyclic Delay Diversity (CDD), Space Time Blocking Code (STBC), Advanced Cel |
Form Factor | External |
Frequency Band | 2.4 GHz, 5 GHz |
Line Coding Format | CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM, 1024 QAM |
Performance | Maximum data rate (5 GHz): 1.2 Gbps | Maximum data rate (2.4 GHz): 287 Mbps | VPN throughput (IPSec): 100 Mbps |
Spread Spectrum Method | OFDM, DSSS, OFDMA |
Status Indicators | Port status, power, system, status, PoE |
Antenna | |
Antenna | Internal |
Antenna Qty | 2 |
Internet of Things (IoT) | |
Communications Technology | Bluetooth Low Energy (LE), Zigbee |
Internet of Things (IoT) Compatible | Yes |
Expansion / Connectivity | |
Interfaces | 2 x 1000Base-T - RJ-45 | 1 x 1000Base-T (PoE+) - RJ-45 | 1 x console - micro-USB |
Miscellaneous | |
Compliant Standards | FCC, EN 60601-1-2, EN 60601-1-1, EMC 2014/30/EU, LVD 2014/35/EU, ISED, RED 2014/53/EU, IEC/EN 62368-1, IEC/EN 60950 |
Pricing Type | BTO |
Power | |
Power Over Ethernet (PoE) Supported | PoE Class 3 |
Dimensions & Weight (Shipping) | |
Shipping Depth | 5.4 cm |
Shipping Height | 16.7 cm |
Shipping Weight | 450 g |
Shipping Width | 11.1 cm |
Manufacturer Warranty | |
Service & Support | Limited warranty - lifetime |
Environmental Parameters | |
Humidity Range Operating | 5 - 93% (non-condensing) |
Max Operating Temperature | 40 °C |
Min Operating Temperature | 0 °C |
TechnicalSpecifications | |
---|---|
Ports | (1) 10/100/1000BASE-T RJ-45 port, auto-sensing link speed and MDI/MDX. (4) 10/100/1000BASE-T (RJ-45) ports, auto-sensing link speed and MDI/MDX |
Mounting | Optional mounting kits: Using one of the (separate orderable) mount kits, the AP can be attached to a single or dual gang wall-box, directly to a wall, or desk mounted. |
Input voltage | IEEE 802.3af Class 3 PoE, or direct DC power (via optional power supply) |
Power consumption | 50W max |
Certifications | Wi-Fi Alliance Wi-Fi CERTIFIED™ a, b, g, n, ac Wi-Fi Alliance Wi-Fi CERTIFIED™ 6 (ax) Wi-Fi Alliance WPA, WPA2 and WPA3 – Enterprise with CNSA option, Personal (SAE), Enhanced Open ( OWE) Wi-Fi Alliance WMM, WMM-PS, Wi-Fi Vantage, Wi-Fi Agile Multiband Wi-Fi Alliance Passpoint (release 2) Ethernet Alliance (POE, PD device, class 6) |
Regulatory | FCC/ISED CE Marked RED Directive 2014/53/EU EMC Directive 2014/30/EU Low Voltage Directive 2014/35/EU IEC/EN 60950 EN 60601-1-1, EN60601-1-2 IEC/EN 62368-1 |
Wi-Fi antenna | Two integrated semi-directional antennas for 2x2 MIMO with peak single antenna gain of 5.2dBi in 2.4GHz and 5.4dBi in 5GHz. Built-in antennas are optimized for vertical wall or desk mounted orientation of the AP. Combining the patterns of each of the antennas of the MIMO radios, the peak gain of the combined, average pattern is 1.7dBi in 2.4GHz and 5.0dBi in 5GHz. |
Radio coverage | 5GHz radio: Two spatial stream (SU/MU) MIMO for up to 1.2Gbps wireless data rate (HE80) 2.4GHz radio: Two spatial stream (SU/MU) MIMO for up to 287Mbps wireless data rate (HE20) |
Product dimensions (metric) | 150 x 86 x 47 mm |
Weight | 360 gm |
