HPE FlexNetwork 5140 24G SFP w/8G Combo 4SFP EI Switch 28-porte Gigabit
HPE FlexNetwork 5140 24G SFP w/8G Combo 4SFP+ EI - Switch - L3 - smart - 24 x Gigabit SFP + 8 x kombi Gigabit Ethernet/Gigabit SFP + 4 x 10 Gigabit Ethernet / 1 Gigabit Ethernet SFP+ - monterbar på stativ
42 265,00 SEK
33 812,00 SEK excl. VAT
-
Product no 999342911
Model JL826A
Brand Hewlett Packard Ente
EAN 0190017497297
Weight 6 kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | HPE FlexNetwork 5140 24G SFP w/8G Combo 4SFP+ EI - switch - 28 porte - smart - monterbar på stativ |
| Enhedstype | Switch - 28 porte - L3 - smart |
| Pakningstype | Monterbar på stativ 1U |
| Undertype | Gigabit Ethernet |
| Porte | 24 x Gigabit SFP + 8 x kombi Gigabit Ethernet/Gigabit SFP + 4 x 10 Gigabit Ethernet / 1 Gigabit Ethernet SFP+ |
| Præstation | Latens (1000 Mbps): 5 µs<br>Latens (10 Gbps): 3 µs<br>Kapacitet: 96 Mpps<br>Routing/switching kapacitet: 128 Gbps |
| Kapacitet | IPv4 indtastning i routing-tabel: 512<br>IPv6 indtastning i routing-tabel: 256<br>VLAN ID'er: 4094 |
| MAC adresse table størrelse | 16.384 indtastninger |
| Jumborammesupport | 9216 byte |
| Routingprotokol | OSPF, RIP-1, RIP-2, IGMP, OSPFv2, IGMPv3, OSPFv3, statisk IPv4 routing, statisk IPv6 routing, CIDR |
| Protokol til fjernadministration | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTPS, TFTP, CLI, NTP, ICMP, RADIUS |
| Egenskaber | Datatransport, understøttet af BOOTP, understøttet af ARP, aktivitet, VLAN-understøttet, auto-uplink (auto MDI/MDI-X), IGMP snooping, DiffServ understøttet, Høj rådighedsgrad, halv dupleksmodus, fuld dupleksmodus, sFlow, STP support, RSTP support, VRRP support, MSTP support, ACL support, QoS, CAR, DHCP server, MDL snooping, DLDP support, STP Root Guard, DHCP videresendelse, LACP, Port Security, Energy Efficient Ethernet, dynamisk ARP beskyttelse, DHCP beskyttelse, MVRP, SPQ, portisolering, GARP, OpenFlow support, IP-kildebekyttelse, ICMP IRDP, Link Aggregation, VLAN Double Tagging (Q-in-Q), LLDP-MED, Smart Link, Guest VLAN, Ethernet OAM, proxy ARP, WRR, IRF Technology, BPDU-beskyttelse, UDP support, MRP |
| Overensstemmelsesstandarder | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ae, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1ad, IEEE 802.3ah, ANSI/TIA-1057, IEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.3az, IEEE 802.1AX, IEEE 802.1r |
| Effekt | AC 100-240 V (50/60 Hz) - strømforsyning ikke installeret |
| Dimensioner (B x D x H) | 44 cm x 36 cm x 4.36 cm |
| Vægt | 6 kg |
| Producentgaranti | Begrænset livtidsgaranti |
HPE Networking Comware Switch 24G SFP w/8G Combo 4SFP+ EI 5140
The HPE Networking Comware Switch Series 5140 EI delivers scalability, high availability, and low TCO at the access layer of medium and large enterprise campus networks. The series offers enterprise-class QoS and security, HPE Intelligent Resilient Fabric (IRF) stacking, static layer 3 routing and RIP; convenient fixed 10 GbE uplink ports, PoE+, ACLs, and IPv6; and delivers energy savings with Energy Efficient Ethernet. The HPE Networking Comware Switch Series 5140 EI also includes Smart Management Center (SmartMC), an embedded network management tool that can be leveraged at no additional cost by small and medium networks for centralized management and operations. The series can also be managed with HPE Aruba Networking IMC for a single view of your entire network.
Gigabit Ethernet access switch with static layer 3 routing, RIP, high density 10 GbE uplinks, and POE+ models for voice, video, and wireless.
It supports IRF technology that enables plug-and-play device aggregation and link aggregation across multiple devices, enhancing network redundancy and resource utilization.
It includes embedded network management capabilities with Smart Management Center (SmartMC).
It includes energy-saving green design features such as automatic switching of idle ports to energy-saving mode and powering down unused ports.
Scalability and High Availability
- The HPE Networking Comware Switch Series 5140 EI delivers scalability and enhances reliability of the network with HPE Intelligent Resilient Framework (IRF) technology. IRF stacking enables virtual resilient switching fabrics, where two or more switches perform as a single L2 switch and L3 router.
- HPE IRF stacking enhances performance and reliability with uninterrupted L2 switching and L3 forwarding and reduces operational complexity with simpler, flatter, and more agile networks.
- Four fixed uplinks (SFP, SFP+, and 10GBASE-T) deliver performance for bandwidth intensive applications.
- Link redundancy with support for protocols such as Spanning Tree/MSTP, RSTP, and Smart link provides high availability.
Comprehensive Security Control
- The HPE Networking Comware Switch Series 5140 EI supports flexible authentication methods including 802.1X and MAC Authentication for greater security and policy-driven application authentication. Per-user access control lists (ACLs) provide identity-driven security and access control.
- ACLs provide IP Layer 2 to Layer 4 traffic filtering while supporting global ACL, VLAN ACL, port ACL, and IPv6 ACL.
- Dynamic ARP protection with functions such as ARP Detection and ARP packet validation that block broadcasts from unauthorized hosts, preventing eavesdropping or theft of network data.
- Centralized security policy management and network protection with HPE Aruba Networking IMC End User Admission Domination (EAD) which integrates security policies, network access control, and access right control policies to form a cooperative security system.
- Enhance security with encryption of access methods (CLI, GUI, or MIB) through SSHv2, SSL, and/or SNMPv3, and other features including DHCP protection, IP source guard, and RADIUS/HWTACAS.
Simplified Management
- The HPE Networking Comware Switch Series 5140 EI can be seamlessly managed with HPE Aruba Networking IMC to provide end-to-end network transparency with a consistent network experience through comprehensive configuration, compliance, and policy management.
- It supports SmartMC, an embedded network management tool with a web-based GUI to simplify operations and facilitate centralized management. It offers features such as configuration backup, software version management and seamless switch replacement.
- RMON and sFlow provide advanced monitoring and reporting capabilities for statistics, history, alarms, and events.
Enhanced Quality of Service
- The HPE Networking Comware Switch Series 5140 EI supports advanced classifier-based QoS which groups traffic using multiple match criteria based on Layer 2 and 3 information; it applies QoS policies such as setting priority level and rate limit to selected traffic on a port, VLAN, or entire switch.
- It provides traffic prioritization with supported congestion actions include: strict priority (SP) queuing, weighted round robin (WRR), weighted random early detection (WRED), and SP+WRR and traffic policing with Committed Access Rate (CAR) and line rate.
- Reduce unwanted network traffic with broadcast control and limitation of broadcast traffic rate to cut down on unwanted network broadcast traffic.
Specifications
| TechnicalSpecifications | |
|---|---|
| Ports | 16 SFP 100/1000 Mbps ports 8 SFP dual-personality ports—10/100/ 1000BASE-T RJ-45 or 100/1000BASE-X Combo Ports 4 SFP+ fixed 1000/10000 SFP+ ports 1 RJ-45 serial console port |
| Memory and processor | 512 MB SDRAM, 256 MB flash |
| Latency | 1000 Mb latency: < 5 µs 10 Gbps latency: < 3 µs |
| Throughput | 95 Mpps |
| Switching capacity | 128 Gbps |
| PoE capability | 370W PoE+ Maximum, depending on model |
| Routing capabilities | Table Size: 1024 entries MAC address: 16,384 entries IPv6 Ready Certified |
| Stacking capabilities | IRF 9 switches |
| Management features | HPE Aruba Networking IMC - Intelligent Management Center SmartMC Command-line interface Web browser SNMP manager |
| Power supply | At least 1 power supply is required (not included, must be ordered separately) |
| Input voltage | AC Voltage: 100 VAC–240 VAC DC Voltage: –48 VDC to –60 VDC |
| Power consumption | 60W (Maximum), 30W (Idle) Notes: Idle power is the actual power consumption of the device with no ports connected. Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated. Power ratings for AC power supply is indicated previously. For DC input power, idle power is 38W and maximum is 68W. DC maximum input current is 8A. Units are supplied without a power supply. Customer must buy 1 or 2 JD362B (AC) or JD366B (DC) power supply. |
| Heat dissipation | Maximum: 102/204 BTU/hr. (107.61/215.22 kJ/hr.) for AC powered units. For DC powered units, heat dissipation is 130 BTU/hr. minimum, 232 BTU/hr. maximum. |
| Product dimensions (metric) | 4.36 x 44 x 36 cm |
| Weight | 6 kg |
