Mean Well SDR-120 series SDR-120-12 120Watt
Mean Well SDR-120 series SDR-120-12 - Strømforsyning (monterbar på DIN rail) - AC 115/230 V - 120 Watt - PFC
899,00 SEK
719,20 SEK excl. VAT
-
Product no 997313820
Model SDR-120-12
Brand Mean Well
EAN 4711287422350
Weight 0.67 kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | Mean Well SDR-120 series SDR-120-12 - strømforsyning - 120 Watt |
| Enhedstype | Strømforsyning - Power Factor Correction (PFC) - monterbar på DIN rail |
| Indgangspænding | AC 115/230 V |
| Udgangspænding | DC 12 V ± 1% |
| Strømkapacitet | 120 Watt |
| Dimensioner (B x D x H) | 4 cm x 12.52 cm x 11.35 cm |
| Producentgaranti | 3 års garanti |
| General | |
|---|---|
| Device Type | Power supply - Power Factor Correction (PFC) - DIN rail mountable |
| Power Device | |
| Efficiency | 89% |
| Frequency Required | 47 - 63 Hz |
| Input Voltage | AC 115/230 V |
| Input Voltage Range | AC 88 - 264 / DC 124 - 370 V |
| Max Electric Current | 10 A |
| Output Voltage | DC 12 V ± 1% |
| Power Capacity | 120 Watt |
| Miscellaneous | |
| Compliant Standards | TUV, EN 61000-3-2, EN 61000-3-3, EN55024, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, EN 61000-4-5, EN 50082-2, EN 61000-6-2, EN 61000-4-11, EN 61000-4-8, UL 508, EN 61204-3, BSMI CNS 14336-1, EN 60204-1, EN 62368-1, CNS 13438 Class B, CI |
| Features | Overheat protection, overvoltage protection, overload protection |
| MTBF | 289,900 hours |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Environmental Parameters | |
| Humidity Range Operating | 20 - 95% (non-condensing) |
| Max Operating Temperature | 70 °C |
| Min Operating Temperature | -25 °C |
| Dimensions & Weight | |
| Depth | 12.52 cm |
| Height | 11.35 cm |
| Width | 4 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Weight | 670 g |
