PowerWalker VFI 3000RM LCD UPS
PowerWalker VFI 3000 CRM LCD - UPS (stativ-monterbar / ekstern) - AC 110-300 V - 2400 Watt - 3000 VA - 9 At - RS-232, USB - output-stikforbindelser: 4 - 2U - 19"
7 461,00 SEK
5 968,80 SEK excl. VAT
-
Product no 989565159
Model 10122002
Brand BlueWalker
EAN 4260074977196
Weight 30.02 kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | PowerWalker VFI 3000 CRM LCD - UPS - 2400 Watt - 3000 VA |
| Enhedstype | UPS - stativ-monterbar / ekstern |
| Rackstørrelse | 19" - 2U |
| Vægt | 29.3 kg |
| Indgangspænding | AC 110-300 V |
| Udgangspænding | AC 200/208/220/230/240 V ± 1% |
| Strømkapacitet | 2400 Watt / 3000 VA |
| Input-stik | 1 x strøm IEC 60320 C20 |
| Output-stikforbindelser | 4 x power IEC 60320 C13<br>1 x terminalblok |
| Batteri | - 9 At |
| Antal batterier | 6 |
| Driftstid (op til) | 4.5 min ved fuld belastning |
| Netværk | RS-232, USB |
| Dimensioner (B x D x H) | 43.8 cm x 63 cm x 8.8 cm |
| General | |
|---|---|
| Device Type | UPS - rack-mountable / external |
| Height (Rack Units) | 2U |
| Rack Size | 19" |
| Power Device | |
| Efficiency | 90% at 100% Load, 88% at 100% Load (battery mode) |
| Frequency Provided | 47 - 53 / 57 - 63 Hz ± 0.3Hz |
| Frequency Required | 40 - 70 Hz |
| Input Connectors | 1 x power IEC 60320 C20 |
| Input Voltage | AC 110-300 V |
| Input Voltage Range | AC 110 - 300 V |
| Output Voltage | AC 200/208/220/230/240 V ± 1% - 47 - 53 / 57 - 63 Hz |
| Output Waveform | Sinewave |
| Power Capacity | 2400 Watt / 3000 VA |
| Power Factor (PF) | 0.99 |
| Power Output Connectors Details | 4 x power IEC 60320 C13 | 1 x terminal block |
| UPS Technology | On-line |
| Battery | |
| Capacity | 9 Ah |
| Quantity | 6 |
| Recharge Time | 9 hours |
| Run Time (Up To) | 4.5 min at full load | 13 min at half load |
| Voltage Provided | 12 V |
| Networking | |
| Remote Management Interface | RS-232, USB |
| Expansion / Connectivity | |
| Expansion Slots | 1 (total) / 1 (free) x expansion slot |
| Interfaces | 1 x management (RS-232) - 9 pin D-Sub (DB-9) | 1 x management (USB) - 4 pin USB Type B |
| Miscellaneous | |
| Cables Included | USB cable - external | Power cable - external |
| Features | LCD display, generator compatible |
| Software / System Requirements | |
| Software Included | ViewPower |
| Environmental Parameters | |
| Humidity Range Operating | 20 - 90% (non-condensing) |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
| Sound Emission | 50 dBA |
| Dimensions & Weight | |
| Depth | 63 cm |
| Height | 8.8 cm |
| Weight | 29.3 kg |
| Width | 43.8 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Depth | 76 cm |
| Shipping Height | 24 cm |
| Shipping Weight | 30 kg |
| Shipping Width | 60 cm |
