PowerWalker VI 3000 RLE UPS

PowerWalker VI 3000 RLE - UPS (rackversion) - AC 230 V - 1800 Watt - 3000 VA - 7.2 At - RS-232, USB - output-stikforbindelser: 8
4 383,00SEK3 506,40SEK excl. VAT
  • Product no 993555819

    Model 10121101

    Brand BlueWalker

    EAN 4260074981193

    Weight 23.6 kg

  • Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
Produktbeskrivelse PowerWalker VI 3000 RLE - UPS - 1800 Watt - 3000 VA
Enhedstype UPS - rackversion
Vægt 21.8 kg
Indgangspænding AC 230 V
Udgangspænding AC 230 V ± 10%
Strømkapacitet 1800 Watt / 3000 VA
Input-stik 1 x strøm IEC 60320 C14
Output-stikforbindelser 8 x power IEC 60320 C13
Batteri - 7.2 At
Antal batterier 4
Driftstid (op til) 1.3 min ved fuld belastning
Netværk RS-232, USB
Udstyr inkluderet Monteringshuller for rack
Dimensioner (B x D x H) 43.8 cm x 43 cm x 8.8 cm
General
Device Type UPS - rack-mountable
Power Device
Circuit Protection Fuse
Dataline Surge Protection Network/phone line - RJ-45/RJ-11 - 1 input line / 1 output line
Efficiency 95%
Frequency Provided 50/60 Hz ± 0.5Hz
Frequency Required 45 - 55 Hz
Input Connectors 1 x power IEC 60320 C14
Input Voltage AC 230 V
Input Voltage Range AC 165 - 290 V
Output Voltage AC 230 V ± 10% - 50/60 Hz
Output Waveform Sinewave
Power Capacity 1800 Watt / 3000 VA
Power Output Connectors Details 8 x power IEC 60320 C13
Surge Suppression Yes
UPS Technology Line interactive
Battery
Capacity 7.2 Ah
Quantity 4
Recharge Time 4 hours
Run Time (Up To) 1.3 min at full load | 7.4 min at half load | 17.8 min at 25% load | 7.4 min at 75% load
Voltage Provided 12 V
Networking
Remote Management Interface RS-232, USB
Expansion / Connectivity
Expansion Slots 1 (total) / 1 (free) x Intelligent Slot
Interfaces 1 x management (USB) - 4 pin USB Type B | 1 x management (RS-232) | 1 x EPO (emergency power off)
Miscellaneous
Cables Included USB cable - external | Serial cable - external
Features LCD display, Automatic Voltage Regulation (AVR), overload protection
Included Accessories Rack mounting ears
Software / System Requirements
Software Included PowerMaster
Dimensions & Weight
Depth 43 cm
Height 8.8 cm
Weight 21.8 kg
Width 43.8 cm
Dimensions & Weight (Shipping)
Shipping Depth 55 cm
Shipping Height 23.1 cm
Shipping Weight 23.6 kg
Shipping Width 55.6 cm
