Dimensions (LxWxH)
|
94 x 19 x 69 mm
|
|
Weight
|
75 g
|
|
Screw terminals max torque
|
0.4 Nm
|
|
Conductor cross section
|
0.5 to 2.5 mm2 / 20 to 14 AWG (green connectors), 1.5 mm2 / 20 to 16 AWG (blue connector)
|
|
Power supply
|
110-240 V~ 50/60 Hz
|
|
Power consumption
|
< 2 W
|
|
External protection
|
max. 10 A, tripping characteristic B or C,6 kA interrupting rating, energy limiting class 3
|
|
Dimming type
|
Trailing edge
|
|
Supported load
|
LED (Dimmable): 200 W, LED (Dimmable): 110 W (On/Off mode), CFL: 50 W, Dimmable electronic transformers: 180 W
|
|
Wi-Fi protocol
|
802.11 b/g/n
|
|
Bluetooth protocol
|
4.2
|
|
CPU
|
ESP32-D0WDQ6
|
|
Flash
|
8 MB
|
|
Schedules
|
20
|
|
Webhooks (URL actions)
|
20 with 5 URLs per hook
|
|
Safety features
|
Temperature protection, Overpower protection (PM devices), Overvoltage load protection (PM devices), Flame Retardant (V-0)
|
