StarTech.com Cisco Meraki MA-SFP-1GB-TX Compatible SFP Module - 10BASE-T - Mbps SFP to RJ45 Cat6/Cat5e Transceiver - 100m SFP (mini-GBIC) transceiver modul
StarTech.com Cisco Meraki MA-SFP-1GB-TX Compatible SFP Module, 1000BASE-T, SFP to RJ45 Cat6/Cat5e, 10/100/1000 Mbps, RJ-45 (Copper) 100m, Cisco Meraki MS225, MX400, MS250, 1GbE Mini GBIC - Lifetime Warranty (MASFP1GBTXST) - SFP (mini-GBIC) transceiver modul (svarende til: Cisco Meraki MA-SFP-1GB-TX) - 1GbE - 1000Base-T - RJ-45 - op til 100 m
-
Product no 992757730
Model MASFP1GBTXST
Brand StarTech.com
EAN 0065030869461
Weight 0.05 kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | StarTech.com Cisco Meraki MA-SFP-1GB-TX Compatible SFP Module, 1000BASE-T, SFP to RJ45 Cat6/Cat5e, 10/100/1000 Mbps, RJ-45 (Copper) 100m, Cisco Meraki MS225, MX400, MS250, 1GbE Mini GBIC - Lifetime Warranty (MASFP1GBTXST) - SFP (mini-GBIC) transceiver modul - 1GbE |
| Enhedstype | SFP (mini-GBIC) transceiver modul - RJ-45 |
| Model | Indstiksmodul |
| Kabeltype | 1000Base-T |
| Dataoverførselshastighed | 1 Gbps |
| Dataforbindelsesprotokol | 1GbE |
| Maks. overføringsafstand | 100 m |
| OEM-producentækvivalent delnummer | Cisco Meraki MA-SFP-1GB-TX |
| Dimensioner (B x D x H) | 1.37 cm x 6.8 cm x 1.38 cm |
| Vægt | 35 g |
| Producentgaranti | Begrænset livtidsgaranti |
| General | |
|---|---|
| Color | Silver |
| Device Type | SFP (mini-GBIC) transceiver module |
| Form Factor | Plug-in module |
| Networking | |
| Cabling Type | 1000Base-T |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab |
| Connectivity Technology | Wired |
| Data Link Protocol | GigE |
| Data Transfer Rate | 1 Gbps |
| Features | Auto-negotiation, full duplex mode |
| Max Transfer Distance | 100 m |
| Expansion / Connectivity | |
| Interfaces | 1 x Ethernet 1000Base-T - RJ-45 female |
| Miscellaneous | |
| Compliant Standards | UL, FCC, RoHS, MSA |
| OEM Manufacturer Equivalent Part Number | Cisco Meraki MA-SFP-1GB-TX |
| Dimensions & Weight | |
| Depth | 6.8 cm |
| Height | 1.38 cm |
| Weight | 35 g |
| Width | 1.37 cm |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime |
| Environmental Parameters | |
| Humidity Range Operating | 5 - 95% |
| Max Operating Temperature | 70 °C |
| Min Operating Temperature | 0 °C |
.jpg)
.jpg)
.jpg)
.jpg)
The MASFP1GBSXST is a Cisco Meraki MA-SFP-1GB-SX compatible copper transceiver module that has been designed, programmed and tested to work with Cisco Meraki™ brand switches and routers. It delivers dependable 1GbE (1000 Mbps) connectivity over copper cable, for 10BASE-T, 1000BASE-T and 100BASE-TX compliant networks, with a maximum distance of up to 100 m (328 ft).
Technical Specifications:
- Maximum Data Transfer Rate: 1000 Mbps
- Type: Copper
- Connection Type: RJ45 Connector
- Maximum Transfer Distance: 100 m (328 ft)
- MTBF: 4,655,371 hours
- Power Consumption: Less than 1.3 Watts
- Digital Diagnostics Monitoring (DDM): No
This SFP copper module is hot-swappable, making upgrades and replacements seamless by minimizing network disruptions.
StarTech.com SFPs
All StarTech.com SFP & SFP+ transceiver modules are backed by a lifetime warranty and free lifetime multilingual technical support. StarTech.com offers a wide variety of SFP modules and direct-attach SFP cables, providing the convenience and reliability you need to ensure dependable network performance.
