StarTech.com Cisco SFP-10G-SR Compatible SFP Module - 10GBASE-SR - 10GE SFP 10GbE Multimode Fiber MMF Optic Transceiver SFP+ transceiver modul 10 Gigabit Ethernet
StarTech.com Cisco SFP-10G-SR Compatible SFP+ Module, 10GBASE-SR, 10GbE Multimode Fiber MMF Optic Transceiver, 10GE Gigabit Ethernet SFP+, LC 300m, 850nm, DDM, Cisco Firepower, ASR9000 - Lifetime Warranty (SFP10GSRST) - SFP+ transceiver modul - 10GbE - 10GBase-SR - LC multimodus - op til 300 m - 850 nm - for P/N: ET10GSFP, PEX10000SFP, PEX10000SFPI, PEX10GSFP, PEX10GSFP4I, PEX20000SFPI
766,00SEK612,80SEK excl. VAT
-
Product no 988493199
Model SFP10GSRST
Brand StarTech.com
EAN 0065030850797
Weight 0.05 kg
-
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
| Produktbeskrivelse | StarTech.com Cisco SFP-10G-SR Compatible SFP+ Module, 10GBASE-SR, 10GbE Multimode Fiber MMF Optic Transceiver, 10GE Gigabit Ethernet SFP+, LC 300m, 850nm, DDM, Cisco Firepower, ASR9000 - Lifetime Warranty (SFP10GSRST) - SFP+ transceiver modul - 10GbE |
| Enhedstype | SFP+ transceiver modul - LC multimodus |
| Model | Indstiksmodul |
| Kabeltype | 10GBase-SR |
| Dataoverførselshastighed | 11.1 Gbps |
| Optisk bølgelængde | 850 nm |
| Dataforbindelsesprotokol | 10GbE |
| Maks. overføringsafstand | 300 m |
| Dimensioner (B x D x H) | 1.2 cm x 6 cm x 1 cm |
| Vægt | 17 g |
| Producentgaranti | Begrænset livtidsgaranti |
| Designet for | P/N: ET10GSFP, PEX10000SFP, PEX10000SFPI, PEX10GSFP, PEX10GSFP4I, PEX20000SFPI |
| General | |
|---|---|
| Device Type | SFP+ transceiver module |
| Form Factor | Plug-in module |
| Networking | |
| Cabling Type | 10GBase-SR |
| Compliant Standards | IEEE 802.3ae |
| Connectivity Technology | Wired |
| Data Link Protocol | 10 GigE |
| Data Transfer Rate | 11.1 Gbps |
| Features | Half duplex mode, full duplex mode, Digital Diagnostics |
| Max Transfer Distance | 300 m |
| Optical Wave Length | 850 nm |
| Expansion / Connectivity | |
| Compatible Slots | 1 x SFP+ |
| Interfaces | 1 x Ethernet 10GBase-SR - LC multi-mode female x 2 |
| Miscellaneous | |
| Compliant Standards | UL, FCC, RoHS, Laser Class 1, MSA |
| Dimensions & Weight | |
| Depth | 6 cm |
| Height | 1 cm |
| Weight | 17 g |
| Width | 1.2 cm |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime |
| Environmental Parameters | |
| Humidity Range Operating | 30 - 70% |
| Max Operating Temperature | 70 °C |
| Min Operating Temperature | 0 °C |
| Compatibility Information | |
| Designed For | P/N: ET10GSFP, PEX10000SFP, PEX10000SFPI, PEX10GSFP, PEX10GSFP4I, PEX20000SFPI |
StarTech.com Cisco Compatible 10GBase-SR SFP+ Fiber Module LC - 300m (DDM)
Add, replace or upgrade SFP+ modules on 10G fiber equipment.
The SFP10GSRST Cisco® Compatible 10GBase-SR SFP+ Fiber Transceiver Module 850nm MM LC w/DDM - 300m (984ft) is built to comply with MSA (Multi-Sourcing Agreement) standards to offer a cost-effective way to add, replace or upgrade a 10Gb SFP+ Multimode LC port on your fiber networking equipment or fiber media converter.
Supporting data rates up to 11.1 Gbps as well as Digital Diagnostics Monitoring (DDM), this LC SFP+/Mini-GBIC module can be installed into any fiber networking device with an MSA or Cisco compliant 10GbE SFP+ port. Delivering both convenience and scalability, this fiber transceiver is fully hot-pluggable, which enables you to install the module without interrupting network traffic or requiring a device reboot.
This 850nm multi-mode SFP+ module is compatible with the Cisco SFP-10G-SR transceiver.
Backed by a StarTech.com lifetime warranty and free lifetime technical support.
Supporting data rates up to 11.1 Gbps as well as Digital Diagnostics Monitoring (DDM), this LC SFP+/Mini-GBIC module can be installed into any fiber networking device with an MSA or Cisco compliant 10GbE SFP+ port. Delivering both convenience and scalability, this fiber transceiver is fully hot-pluggable, which enables you to install the module without interrupting network traffic or requiring a device reboot.
This 850nm multi-mode SFP+ module is compatible with the Cisco SFP-10G-SR transceiver.
Backed by a StarTech.com lifetime warranty and free lifetime technical support.
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
StarTech.com Advantage
- Cost-effective replacement for MSA or Cisco compliant equipment
- Extend network connectivity up to 300m
Product Features
- Maximum data rates up to 11.1Gbps
- Supports distances up to 300m (984ft)
- Complies with SFP Multi-Source Agreements standards (MSA)
- Compatible with Cisco equipment
- LC Fiber connector
- Fully Hot Pluggable
Product Applications
- Replacing defective or damaged SFP+ modules in 10Gb MSA compliant or Cisco equipment
- Expand your network to remote segments
