Produktbeskrivelse
|
Teltonika TRB140 - gateway
|
|
Enhedstype
|
Gateway
|
|
Formfaktor
|
Ekstern
|
|
Lokalisering
|
Europa
|
|
Processor
|
1 x ARM Cortex-A7 1.2 GHz
|
|
RAM
|
128 MB
|
|
Flashhukommelse
|
512 MB
|
|
Dataforbindelsesprotokol
|
Ethernet, Fast Ethernet, Gigabit Ethernet
|
|
Kapacitet
|
VPN-tunneler: 5
|
|
Mobilt bredbåndsadgang
|
Ja
|
|
Mobilprotokol
|
GSM, GPRS, UMTS, EDGE, HSPA+, FDD LTE
|
|
Mobilt net
|
LTE B1/B20/B28/B3/B7/B8
|
|
Udstyr inkluderet
|
LTE-antenne, hex-nøgle
|
|
Dimensioner (B x D x H)
|
6 cm x 7 cm x 1.8 cm
|
|
Vægt
|
134 g
|
Denmark's wildest electronics webshop is now available in Sweden
Teltonika TRB140 Gateway Ekstern
Teltonika TRB140 - Gateway - 1GbE - LTE B1/B20/B28/B3/B7/B8
SEK 1 466,00
SEK 1 172,80 excl. VAT
SEK 1 466,00
SEK 1 172,80 excl. VAT
Shipping from SEK 39,00 (PostNord Spårbart varubrev)
Specifications
Full specifications
|
General
|
|
|---|---|
|
Depth
|
7 cm
|
|
Device Type
|
Gateway
|
|
Height
|
1.8 cm
|
|
Localization
|
Europe
|
|
Weight
|
134 g
|
|
Width
|
6 cm
|
|
Processor / Memory / Storage
|
|
|
Flash Memory
|
512 MB
|
|
Max Supported Qty
|
1
|
|
Processors Installed
|
1 x ARM Cortex-A7 1.2 GHz
|
|
RAM
|
128 MB
|
|
Networking
|
|
|
Authentication Method
|
X.509 certificates
|
|
Capacity
|
VPN tunnels: 5
|
|
Connectivity Technology
|
Wireless, wired
|
|
Data Link Protocol
|
Ethernet, Fast Ethernet, Gigabit Ethernet
|
|
Encryption Algorithm
|
DES, Triple DES, RC2, IKE, TLS, SSL 3.0, 128-bit AES, 192-bit AES, 256-bit AES, IKEv2, 256-bit AES-CBC, 128-bit AES-CBC, 192-bit AES-CBC
|
|
Features
|
Firewall protection, NAT support, VPN support, wake on LAN (WOL), auto-uplink (auto MDI/MDI-X), MAC address filtering, firmware upgradable, IPSec NAT-Traversal (NAT-T), port forwarding, reset button, DIN rail mountable, GRE tunneling, Firmware Over-t
|
|
Form Factor
|
External
|
|
Network / Transport Protocol
|
TCP/IP, PPTP, UDP/IP, L2TP, NTP, ICMP/IP, IPSec, DHCP, DNS, DDNS, IPv4, IPv6
|
|
Remote Management Protocol
|
HTTP, HTTPS, SSH, SSH-2, CLI, JSON-RPC, Modbus, MQTT
|
|
Routing Protocol
|
Static IP routing, GRE
|
|
Status Indicators
|
Power, signal, data
|
|
Antenna
|
|
|
Antenna
|
External detachable
|
|
Antenna Qty
|
1
|
|
Directivity
|
Omni-directional
|
|
Gain Level
|
2 dBi
|
|
Communications
|
|
|
Cellular Band
|
LTE B1/B20/B28/B3/B7/B8
|
|
Cellular Protocol
|
GSM, GPRS, UMTS, EDGE, HSPA+, FDD LTE
|
|
Mobile Broadband Access
|
Yes
|
|
Internet of Things (IoT)
|
|
|
Communications Technology
|
LTE Cat 4
|
|
Internet of Things (IoT) Compatible
|
Yes
|
|
Expansion / Connectivity
|
|
|
Expansion Slots
|
1 (total) / 1 (free) x SIM card
|
|
Interfaces
|
1 x USB - micro-USB | 1 x antenna - SMA | 1 x 1000Base-T - RJ-45 | 2 x digital input/output - terminal block
|
|
Miscellaneous
|
|
|
Cables Included
|
1 x micro-USB cable - 80 cm | 1 x network cable
|
|
Compliant Standards
|
RoHS, WEEE, IP30, EAC, EN 61000-4-2:2009, EN 61000-4-11:2004, EN 61000-4-3:2006+A1:2008+A2:2010, EN 61000-4-6:2014, EN 61000-4-5:2014, EN 61000-4.4:2012, RED, IEC 62368-1: 2014 Second Edition, EN 62368-1:2014+A11:2017, ETSI EN 301 908-1 V11.1.1, ETSI
|
|
Included Accessories
|
LTE antenna, hex key
|
|
Power
|
|
|
Power Consumption Operational
|
5 Watt
|
|
Power Device
|
External power adapter
|
|
Software / System Requirements
|
|
|
OS Provided
|
RutOS
|
|
Environmental Parameters
|
|
|
Humidity Range Operating
|
10 - 90% (non-condensing)
|
|
Max Operating Temperature
|
75 °C
|
|
Min Operating Temperature
|
-40 °C
|
