TP-Link JetStream TL-SG2210MP Switch 10-porte Gigabit PoE+
TP-Link JetStream TL-SG2210MP - Switch - smart - 8 x 10/100/1000 (PoE+) + 2 x SFP - monterbar på stativ - PoE+ (150 W)
SEK 1 870,00
SEK 1 496,00 excl. VAT
SEK 1 870,00
SEK 1 496,00 excl. VAT
Free shipping (PostNord Paketbutik)
Product no:
996135527
Model:
TL-SG2210MP
EAN:
6935364030674
Brand:
Weight:
2.26 kg
Product information and specifications are guiding only. Without notice, these can be subject to change by the manufacturer. This applies for product images as well.
Specifications
|
Produktbeskrivelse
|
TP-Link JetStream TL-SG2210MP - switch - 10 porte - smart - monterbar på stativ
|
|
Enhedstype
|
Switch - 10 porte - smart
|
|
Pakningstype
|
Monterbar på stativ
|
|
Undertype
|
Gigabit Ethernet
|
|
Porte
|
8 x 10/100/1000 (PoE+) + 2 x SFP
|
|
Power Over Ethernet (PoE)
|
PoE+
|
|
PoE-budget
|
150 W
|
|
Præstation
|
Omkoblingskapacitet: 20 Gbps<br>Fremsendelsespræstation: 14.9 Mpps
|
|
MAC adresse table størrelse
|
8K indtastningshukommelse
|
|
Jumborammesupport
|
9KB
|
|
Routingprotokol
|
IGMPv2, IGMP, IGMPv3, MLDv2, MLD
|
|
Protokol til fjernadministration
|
SNMP 1, SNMP, Telnet, SNMP 3, SNMP 2c, TFTP, SSH, DHCP, IPv4, IPv6
|
|
Egenskaber
|
Datatransport, auto-uplink (auto MDI/MDI-X), IGMP snooping, portspejling, STP support, RSTP support, MSTP support, DHCP snooping, ACL support, QoS, MDL snooping, båndbreddekontrol, DLDP support, 512 KB pakkebuffer, NDP, CoS, SP, GVRP, Storm Control, BPDU, Link Aggregation, AAA, 1 blæser, Voice VLAN, IPMB, ZTP, WRR, tilbageløkke-detektion, MLD, DSCP-prioritering
|
|
Overensstemmelsesstandarder
|
IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at, IEEE 802.3az
|
|
Effekt
|
AC 120/230 V (50/60 Hz)
|
|
Dimensioner (B x D x H)
|
29.4 cm x 18 cm x 4.4 cm
|
Full specifications
|
General
|
|
|---|---|
|
Authentication Method
|
Secure Shell (SSH), RADIUS, PAP, Secure Shell v.2 (SSH2), Extensible Authentication Protocol (EAP), EAP-TLS, EAP-TTLS
|
|
Compliant Standards
|
IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3at, IEEE 802.3az
|
|
Device Type
|
Switch - 10 ports - smart
|
|
Enclosure Type
|
Rack-mountable
|
|
Encryption Algorithm
|
SSL, SSL 3.0, TLS 1.2
|
|
Features
|
Flow control, auto-uplink (auto MDI/MDI-X), IGMP snooping, port mirroring, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Access Control List (ACL) sup
|
|
Jumbo Frame Support
|
9KB
|
|
MAC Address Table Size
|
8K entries
|
|
Performance
|
Switching capacity: 20 Gbps | Forwarding performance: 14.9 Mpps
|
|
PoE Budget
|
150 W
|
|
Ports
|
8 x 10/100/1000 (PoE+) + 2 x SFP
|
|
Power Over Ethernet (PoE)
|
PoE+
|
|
Remote Management Protocol
|
SNMP 1, SNMP, Telnet, SNMP 3, SNMP 2c, TFTP, SSH, DHCP, IPv4, IPv6
|
|
Routing Protocol
|
IGMPv2, IGMP, IGMPv3, MLDv2, MLD
|
|
Subtype
|
Gigabit Ethernet
|
|
Expansion / Connectivity
|
|
|
Interfaces
|
8 x 1000Base-T RJ-45 PoE+ | 2 x Gigabit LAN SFP
|
|
Power
|
|
|
Power Consumption Operational
|
173.9 Watt
|
|
Power Device
|
Internal power supply
|
|
Voltage Required
|
AC 120/230 V (50/60 Hz)
|
|
Miscellaneous
|
|
|
Compliant Standards
|
FCC, RoHS
|
|
Included Accessories
|
Rubber feet
|
|
Rack Mounting Kit
|
Included
|
|
Dimensions & Weight
|
|
|
Depth
|
18 cm
|
|
Height
|
4.4 cm
|
|
Width
|
29.4 cm
|
|
Environmental Parameters
|
|
|
Humidity Range Operating
|
10 - 90% (non-condensing)
|
|
Humidity Range Storage
|
5 - 90% (non-condensing)
|
|
Max Operating Temperature
|
50 °C
|
|
Max Storage Temperature
|
70 °C
|
|
Min Operating Temperature
|
0 °C
|
|
Min Storage Temperature
|
-40 °C
|
