Product no 987745270
Model TL-SG2008
Brand
Go to brand's website
EAN 6935364021788
Weight 0.93 kg
Produktbeskrivelse | TP-Link TL-SG2008 - switch - 8 porte - Administreret |
Enhedstype | Switch - 8 porte - Administreret |
Undertype | Gigabit Ethernet |
Porte | 8 x 10/100/1000 |
Præstation | Båndbredde: 16 Gbps<br>Fremsendelsespræstation: 11.9 Mpps |
Kapacitet | Virtuelle grænseflader (VLANs): 512 |
MAC adresse table størrelse | 8K indtastningshukommelse |
Jumborammesupport | 9216 byte |
Protokol til fjernadministration | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c, SSH, CLI |
Egenskaber | Datatransport, auto-negotiation, VLAN-understøttet, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog understøttet, portspejling, Weighted Round Robin (WRR) kø, firmware kan opgraderes, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Quality of Service (QoS), nulstillingsknap, blæserløs, LACP support, Strict Priority (SP), Loopback |
Overensstemmelsesstandarder | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s |
Effekt | AC 120/230 V (50/60 Hz) |
Dimensioner (B x D x H) | 20.9 cm x 12.6 cm x 2.6 cm |
General | |
---|---|
Capacity | Virtual interfaces (VLANs): 512 |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s |
Device Type | Switch - 8 ports - managed |
Enclosure Type | Desktop |
Features | Flow control, auto-negotiation, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, Syslog support, port mirroring, Weighted Round Robin (WRR) queuing, firmware upgradable, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RS |
Jumbo Frame Support | 9216 bytes |
MAC Address Table Size | 8K entries |
Performance | Bandwidth: 16 Gbps | Forwarding performance: 11.9 Mpps |
Ports | 8 x 10/100/1000 |
Remote Management Protocol | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c, SSH, CLI |
Status Indicators | Port transmission speed, power, system |
Subtype | Gigabit Ethernet |
Expansion / Connectivity | |
Interfaces | 8 x 1000Base-T RJ-45 |
Power | |
Power Device | External power adapter |
Voltage Required | AC 120/230 V (50/60 Hz) |
Miscellaneous | |
Compliant Standards | FCC, RoHS |
Software / System Requirements | |
Software Included | Drivers & Utilities |
Dimensions & Weight | |
Depth | 12.6 cm |
Height | 2.6 cm |
Width | 20.9 cm |
Environmental Parameters | |
Humidity Range Operating | 10 - 90% (non-condensing) |
Humidity Range Storage | 5 - 90% (non-condensing) |
Max Operating Temperature | 40 °C |
Max Storage Temperature | 70 °C |
Min Operating Temperature | 0 °C |
Min Storage Temperature | -40 °C |
