Product no 995634964
Model TPE-3018LS
Brand
Go to brand's website
EAN 0710931161526
Weight 0.99 kg
Produktbeskrivelse | TRENDnet TPE 3018LS - switch - 18 porte - smart - monterbar på stativ - TAA-kompatibel |
Enhedstype | Switch - 18 porte - smart |
Pakningstype | Monterbar på stativ 1U |
Undertype | Gigabit Ethernet |
Porte | 8 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP |
Power Over Ethernet (PoE) | PoE+ |
PoE-budget | 220 W |
Præstation | Omkoblingskapacitet: 36 Gbps<br>Skift af stofbåndbredde: 36 Gbps<br>Videresendelsespræstation (64-byte pakkestørrelse): 26,7 Mpps |
Kapacitet | VLAN-grupper: 256 |
MAC adresse table størrelse | 8K indtastningshukommelse |
Jumborammesupport | 10KB |
Protokol til fjernadministration | SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH-2, CLI |
Egenskaber | VLAN-understøttet, IGMP snooping, Syslog understøttet, portspejling, Broadcast Storm Control, IPv6 understøttet, halv dupleksmodus, fuld dupleksmodus, Multicast Storm Control, Unicast Storm Control, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Quality of Service (QoS), Cable Diagnostics Function, Uni-Directional Link Detection (UDLD), IPv4 support, blæserløs, LACP support, LLDP support, Port Security, 512 KB pakkebuffer, Multicast VLAN Registration (MVR), mærket VLAN, ONVIF support, båndbreddekontrol pr. port, DiffServ Code Point (DSCP) support, IP-kildebekyttelse, Head of Line Blocking Prevention, IGMP-forespørger, beskyttede porte, Denial of Service (DoS) protection, tilbageløkke-detektion, IGMP omgående forlad, Unknown Storm Control |
Overensstemmelsesstandarder | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az |
Effekt | AC 120/230 V (50/60 Hz) |
Dimensioner (B x D x H) | 44 cm x 19.5 cm x 4.445 cm |
Vægt | 2.93 kg |
TAA kompatibel | Ja |
Producentgaranti | Begrænset livtidsgaranti |
General | |
---|---|
Built-in Devices | LED display |
Capacity | VLAN groups: 256 |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az |
Device Type | Switch - 18 ports - smart |
Enclosure Type | Rack-mountable 1U |
Features | VLAN support, IGMP snooping, Syslog support, port mirroring, Broadcast Storm Control, IPv6 support, half duplex mode, full duplex mode, Multicast Storm Control, Unicast Storm Control, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol |
Jumbo Frame Support | 10KB |
MAC Address Table Size | 8K entries |
Performance | Switching capacity: 36 Gbps | Switching fabric bandwidth: 36 Gbps | Forwarding performance (64-byte packet size): 26.7 Mpps |
PoE Budget | 220 W |
Ports | 8 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP |
Power Over Ethernet (PoE) | PoE+ |
Remote Management Protocol | SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH-2, CLI |
Subtype | Gigabit Ethernet |
Expansion / Connectivity | |
Interfaces | 16 x 1000Base-T RJ-45 PoE+ - 30 W | 2 x 1000Base-T RJ-45 | 2 x Gigabit LAN SFP |
Power | |
Power Consumption Operational | 14 Watt |
Power Device | Internal power supply |
Voltage Required | AC 120/230 V (50/60 Hz) |
Miscellaneous | |
Compliant Standards | FCC, ETL |
Rack Mounting Kit | Included |
Dimensions & Weight | |
Depth | 19.5 cm |
Height | 4.445 cm |
Weight | 2.93 kg |
Width | 44 cm |
Manufacturer Warranty | |
Service & Support | Limited warranty - lifetime |
Environmental Parameters | |
Humidity Range Operating | 0 - 90% (non-condensing) |
Max Operating Temperature | 40 °C |
Min Operating Temperature | 0 °C |
