Product no 1001101857
Model VIGI NVR1104H-4P
Brand TP-LINK Technologies
EAN 4897098688786
Weight 1.41 kg
Produktbeskrivelse | TP-Link VIGI NVR1104H-4P V1 - standalone NVR - 4 kanaler |
Enhedstype | NVR - 4 kanaler - netværket |
Understøttede IP Kameraer | 4 |
Komprimerings Format | H.264, H.265, H.264+, H.265+ |
Billed Opløsning | 1280x720, 1920x1080, 1024x768, 1680x1050, 1280x1024, 1440x900, 3840x2160 |
Understøttede HardDrev | Antal: 1 - total kapacitet: 10 TB |
Spænding | 53.5 V |
Dimensioner (B x D x H) | 20.03 cm x 20.03 cm x 4.3 cm |
General | |
---|---|
Compliant Standards | Plug and Play, IEEE 802.3af, IEEE 802.3at |
Compression Format | H.264, H.265, H.264+, H.265+ |
Device Type | NVR |
Image Resolution | 1280x720, 1920x1080, 1024x768, 1680x1050, 1280x1024, 1440x900, 3840x2160 |
IP Cameras Supported | 4 |
Package Content | Mouse, HDD screws |
Video Channels | 4 |
Security DVR | |
Features | 80Mbps Incoming Bandwidth, 60Mbps Outgoing Bandwidth, built-in speaker |
Networked | Yes |
Hard Drive | |
Interface | Serial ATA |
Quantity Supported | 1 |
Removable | Yes |
Supported Max Total Capacity | 10 TB |
Video Server | |
Features | Two-way audio support |
Networking | |
Features | ONVIF support, remote access management, 53W PoE+ power budget |
Network Interfaces | Ethernet 10Base-T/100Base-TX |
Supported Protocols | DHCP, DNS, HTTP, NTP, TCP/IP, HTTPS, UPnP |
Connections | |
Audio Input Ports | RCA x 1 |
Audio Output Ports | RCA x 1 |
Network Port | 10/100Base-T |
Other Ports | USB 2.0 x 2 |
Video Input Ports | RJ-45 x 4 |
Video Output Ports | HDMI x 1, VGA x 1 |
Power | |
Power Consumption | 4.82 Watt |
Power Consumption Details | Without HDD |
Voltage | 53.5 V |
Dimensions & Weight | |
Depth | 20.03 cm |
Height | 4.3 cm |
Width | 20.03 cm |
Environmental Parameters | |
Max Operating Temperature | 55 °C |
Min Operating Temperature | -10 °C |
