Zyxel GS1005HP Switch 5-porte Gigabit PoE
Zyxel GS1005HP - Switch - ikke administreret - 4 x 10/100/1000 (PoE+) + 1 x 10/100/1000 - desktop, væg-monterbar - PoE (60 W)
Varenummer:
993853379
Model:
GS1005HP-EU0101F
EAN:
4718937603923
Brand:
Vægt:
0.87 kg
Specifications
|
Produktbeskrivelse
|
Zyxel GS1005HP - switch - 5 porte - ikke administreret
|
|
Enhedstype
|
Switch - 5 porte - ikke administreret
|
|
Undertype
|
Gigabit Ethernet
|
|
Porte
|
4 x 10/100/1000 (PoE+) + 1 x 10/100/1000
|
|
Power Over Ethernet (PoE)
|
PoE
|
|
PoE-budget
|
60 W
|
|
Præstation
|
Omkoblingskapacitet: 10 Gbps
|
|
MAC adresse table størrelse
|
2K indtastningshukommelse
|
|
Jumborammesupport
|
9KB
|
|
Egenskaber
|
Datatransport, komplet duplex ydeevne, auto-negotiation, auto-uplink (auto MDI/MDI-X), gem og send, QoS, blæserløs, 128 KB pakkebuffer, løkkeforebyggelse, EEE
|
|
Overensstemmelsesstandarder
|
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3az
|
|
Effekt
|
AC 120/230 V (50/60 Hz)
|
|
Dimensioner (B x D x H)
|
12.1 cm x 7.5 cm x 2.6 cm
|
|
Vægt
|
235 g
|
|
Lokalisering
|
Europa
|
Full specifications
|
General
|
|
|---|---|
|
Compliant Standards
|
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3az
|
|
Device Type
|
Switch - 5 ports - unmanaged
|
|
Enclosure Type
|
Desktop, wall-mountable
|
|
Features
|
Flow control, full duplex capability, auto-negotiation, auto-uplink (auto MDI/MDI-X), store and forward, Quality of Service (QoS), fanless, 128KB packet buffer, loop prevention, Energy-Efficient Ethernet (EEE)
|
|
Jumbo Frame Support
|
9KB
|
|
MAC Address Table Size
|
2K entries
|
|
Performance
|
Switching capacity: 10 Gbps
|
|
PoE Budget
|
60 W
|
|
Ports
|
4 x 10/100/1000 (PoE+) + 1 x 10/100/1000
|
|
Power Over Ethernet (PoE)
|
PoE
|
|
Status Indicators
|
Power, PoE, link/activity
|
|
Subtype
|
Gigabit Ethernet
|
|
Expansion / Connectivity
|
|
|
Interfaces
|
4 x 1000Base-T RJ-45 PoE+ - 30 W | 1 x 1000Base-T RJ-45
|
|
Power
|
|
|
Power Consumption Operational
|
72 Watt
|
|
Power Device
|
External power adapter
|
|
Voltage Required
|
AC 120/230 V (50/60 Hz)
|
|
Miscellaneous
|
|
|
Compliant Standards
|
BSMI, EMC, FCC, LVD
|
|
Included Accessories
|
Rubber pad
|
|
Localization
|
Europe
|
|
Dimensions & Weight
|
|
|
Depth
|
7.5 cm
|
|
Height
|
2.6 cm
|
|
Weight
|
235 g
|
|
Width
|
12.1 cm
|
|
Dimensions & Weight (Shipping)
|
|
|
Shipping Depth
|
13.2 cm
|
|
Shipping Height
|
7.8 cm
|
|
Shipping Weight
|
834 g
|
|
Shipping Width
|
21 cm
|
|
Environmental Parameters
|
|
|
Humidity Range Operating
|
10 - 90% (non-condensing)
|
|
Humidity Range Storage
|
10 - 90% (non-condensing)
|
|
Max Operating Temperature
|
40 °C
|
|
Max Storage Temperature
|
70 °C
|
|
Min Operating Temperature
|
0 °C
|
|
Min Storage Temperature
|
-40 °C
|
