Case Type
|
Mid Tower
|
|
Colors
|
Black
|
|
Body Material
|
SGCC
|
|
Steel Thickness
|
0.8 mm
|
|
Motherboards
|
ATX / Micro ATX / Mini-ITX
|
|
Case Dimensions (D x W x H)
|
466 x 309 x 500 mm
|
|
Capacity
|
71 L
|
|
3.5” Drive Bays
|
1 Max. (1 x 3.5” / 2 x 2.5″)
|
|
2.5” Drive Bays
|
4 Max. (2 x 2.5” and 1 x 3.5” / 2 x 2.5″)
|
|
Expansion Slots
|
7
|
|
GPU Clearance
|
Supports GPU up to 445mm (W/O radiator in the front-right position)
|
|
CPU Cooler Clearance
|
Supports CPU cooler up to 183mm
|
|
Fan Support Right-Front
|
120mm x 3 or 140mm x 3 (Max.)
|
|
Fan Support Right-Top
|
120mm x 3 (Max.)
|
|
Fan Support Top
|
120mm x 3 or 140mm x 3 (Max.)
|
|
Fan Support Bottom
|
120mm x 3 or 140mm x 3 or 160mm x 2 (Max.) (3x FP3-140 Case Version included)
|
|
Fan Support Rear
|
120mm x 2 or 140mm x 1 (Max.) (1x FP3-140 Case Version included)
|
|
Radiator Support Right-Front
|
120 / 140 / 240 / 280 / 360mm Radiator (Optional)
|
|
Radiator Support Right-Top
|
120 / 240 / 360mm Radiator (Optional)
|
|
Radiator Support Top
|
120/140/240/360mm Radiator (Optional)
|
|
Radiator Support Bottom
|
120 / 140 / 240 / 280 / 360 Radiator (Optional) (Remove bottom fan filter)
|
|
Radiator Support Rear
|
120mm Radiator (Optional)
|
|
I/O Ports
|
USB3.2 Gen 2×2 Type-C x 1 | USB3.2 Gen 1 Type -A x 2 | HD Audio & Mic.
|
|
Weight
|
11.8 KG
|
|
Internal Cable Management Depth
|
99mm
|
|
Power Supply Support
|
ATX PSU (Including cables, up to 270mm) (Optional)
|
