Product no 997171389
Model TL-SG3428X
Brand
Go to brand's website
EAN 6935364010522
Weight 2.71 kg
Produktbeskrivelse | TP-Link JetStream TL-SG3428X - V1 - switch - 28 porte - Administreret - monterbar på stativ |
Enhedstype | Switch - 28 porte - Administreret |
Pakningstype | Monterbar på stativ |
Undertype | Gigabit Ethernet |
Porte | 24 x 10/100/1000 + 4 x 10 Gigabit SFP+ |
Præstation | Omkoblingskapacitet: 128 Gbps<br>Pakkevideresendelseshastighed: 95.23 Mpps |
Kapacitet | Prioritetskøer: 8<br>VLAN-grupper: 4000 |
MAC adresse table størrelse | 16K indtastningshukommelse |
Jumborammesupport | 9KB |
Routingprotokol | IGMPv2, IGMP, IGMPv3, statisk IPv4 routing, statisk IPv6 routing, MLDv2, MLD, MSTP, RSTP, STP |
Protokol til fjernadministration | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, CLI, ICMP, DHCP, RSTP |
Egenskaber | Datatransport, VPN support, understøttet af BOOTP, understøttet af ARP, IGMP snooping, Syslog understøttet, DoS attack beskyttelse, portspejling, Broadcast Storm Control, IPv6 understøttet, Multicast Storm Control, Unicast Storm Control, firmware kan opgraderes, SNTP-understøttet, sFlow, DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), DHCP server, MDL snooping, Cable Diagnostics Function, båndbreddekontrol, Device Link Detection Protocol (DLDP) support, blæserløs, LLDP support, DHCP videresendelse, Link Aggregation Control Protocol (LACP), Port Security, Multicast VLAN Registration (MVR), Neighbor Discovery Protocol (NDP), portisolering, 12 MB pakkebuffer, Class of Service (CoS), Strict Priority (SP), Generic VLAN Registration Protocol (GVRP), 802.1x autentificering, sky-administreret, DiffServ Code Point (DSCP) support, IP-kildebekyttelse, ARP-inspektion, Bridge protocol data unit (BPDU), dobbelt billedsupport, Software Defined Networking (SDN), Authentication, Authorization and Accounting (AAA), LLDP-MED, VLAN-gruppe, gæsteadgang, Zero-touch provisioning (ZTP), Energy-Efficient Ethernet (EEE), BPDU Filter, Weighted Round Robin (WRR), Head-of-line (HOL) Blocking Prevention, tilbageløkke-detektion, Advanced QoS, MAC Access Bypass (MAB), sikkerhedsåbning (Kensington-sikkerhedslåskompatibel) |
Overensstemmelsesstandarder | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP) |
Effekt | AC 120/230 V (50/60 Hz) |
Dimensioner (B x D x H) | 44 cm x 18 cm x 4.4 cm |
General | |
---|---|
Authentication Method | Secure Shell (SSH), RADIUS, TACACS+, Secure Shell v.2 (SSH2) |
Capacity | Priority queues: 8 | VLAN groups: 4000 |
Compliant Standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP) |
Device Type | Switch - 28 ports - managed |
Enclosure Type | Rack-mountable |
Encryption Algorithm | SSL 3.0, TLS 1.2 |
Features | Flow control, VPN support, BOOTP support, ARP support, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, firmware upgradable, SNTP support, sFl |
Jumbo Frame Support | 9KB |
MAC Address Table Size | 16K entries |
Performance | Switching capacity: 128 Gbps | Packet forwarding rate: 95.23 Mpps |
Ports | 24 x 10/100/1000 + 4 x 10 Gigabit SFP+ |
Remote Management Protocol | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, CLI, ICMP, DHCP, RSTP |
Routing Protocol | IGMPv2, IGMP, IGMPv3, static IPv4 routing, static IPv6 routing, MLDv2, MLD, MSTP, RSTP, STP |
Status Indicators | Status |
Subtype | Gigabit Ethernet |
Expansion / Connectivity | |
Interfaces | 24 x 1000Base-T RJ-45 | 4 x 10GBase-X SFP | 1 x console RJ-45 | 1 x micro-USB console |
Power | |
Power Consumption Operational | 23.6 Watt |
Power Device | Internal power supply |
Voltage Required | AC 120/230 V (50/60 Hz) |
Miscellaneous | |
Compliant Standards | FCC, RoHS |
Included Accessories | Rubber feet |
Rack Mounting Kit | Included |
Dimensions & Weight | |
Depth | 18 cm |
Height | 4.4 cm |
Width | 44 cm |
Environmental Parameters | |
Humidity Range Operating | 10 - 90% (non-condensing) |
Humidity Range Storage | 5 - 90% (non-condensing) |
Max Operating Temperature | 45 °C |
Max Storage Temperature | 70 °C |
Min Operating Temperature | 0 °C |
Min Storage Temperature | -40 °C |
